After-sales Service : Engineers Available to Service Overseas
Warranty : 1 Year
Type : Fiber Laser Marking Machine
Laser Visibility : Visible
Applicable Material : Metal & Some Nonmetal
Cooling System : Air Cooling
Technical Class : Pulse Laser
Laser Classification : Solid Laser
Marking Method : Scanning Marking
Scanning Speed : 0-12000mm/s
Marking Depth:0.01-0.2mm (adjustable)
Transport Package : Plastic Foam Film or Plywood Case
Specification : 20W /30W/ 50W
Trademark : Polywell
Origin : Zhangjiagang City, China
Voltage : 220V
Product Description
1) Compact design and fast installation.
2) Easy to be integrated at any position of the production line.
3) Environmental protection and energy saving.
4) Un-contact processing, lower power, fast laser marked and cost economy.
5) Easy to use and excellent compatibility.
6) Simplicity of operation, easy to use, powerful anti-jamming performance, enough memory, multiply input and output interface.
7) Adopt fiber laser, safer and faster, long-life.
8) The laser printer needn't consumable.
9) High-speed, stable performance, adjustable power, applicable to all metal materials and most nonmetal material.
10) Carve and cut product very convenience, depth could be adjustable.

Application
Printing industry: Building materials industries, pipe, wire and cable, food, beverages, alcohol, chemical, automotive, pharmaceuticals, cosmetics, and etc.
Printing content: Date, time, batch number, logo, serial number, design, bar code, security code, multiple font, and etc.
| Model | PWST-1020 | PWS-1020 | PWSS-2020 | PWDS-2040 | PWSS-3020 | PWDS-3040 |
| Laser Source | 20W | 20W | 20W | 40W | 20W | 40W |
| Marking Mode | Static marking | Dynamic marking | ||||
| Laser Type | Fiber | |||||
| Refrigerate Style | Air-cooled | |||||
| Application | All metallic materials and most non-metallic materials | |||||
| Marking Depth | ≤0.2mm (depending on the material) | |||||
| Line Width | 0.02mm | |||||
| Text Type | Fixed text, serial number, date, counter, shift code, random code etc. | |||||
| User Interface | 1 | 1 | 1 | 2 | 1 | 2 |
| Marking position | Single side | Single side | Single side | Double side | Single side | Double side |
| Operation Temperature | 5-38 ℃ | |||||
| Engraving Line Speed | ≤12000mm/s | |||||
| Repeatability Accuracy | ±0.001mm | |||||
| Voltage | 220V 50Hz | |||||
| Weight | 100kg | 100kg | 150kg | 180kg | ||
